Reflex Level Gauge

Introduction: The SCS Level gauges are used for measuring the level in the vessel.These can be used for maximum pressure of Upto150kg/cm2 and a maximum temperature of 400°C .Constructional features include 2.5 meter single piece construction with multiple glasses between process connection. A pair of auto shut off ball check valves in material of construction carbon steel or stainless steel and polypropylene as optional.

Principle :

The principal of reflex level gauges is based on the difference in the refractive indices of liquid & vapour. The liquid column is contained within the recess of liquid chamber behind the sight glass which is clamped to the gauge body.The Sight glass has prismatic right angled grooves on the side facing the liquid and vapour space light raise entering from right outside the gauge are either absorbed or reflected depending upon whether they enter the liquid or vapour space. When the ray of light encounters the surface of one of the grooves in vapour space, it is reflected to the opposite space appears as silvery white. When the light ray encounters the surface of grooves in the liquid space, it is totally absorbed thereby the liquid behind the glass appear black.

Max Temperature:	400°C
Max Pressure:	150kg/cm2
Pair of Valves:	SCS-2500 offset integral with bonnet with ball check arrangement. SCS-3500 offset, design bolted bonnet, renewable seats and ball check arrangement.

Specifications:

C-C Distance Up to 100"; single piece liquid chamber Chamber CS, SS304, SS316, polypropylene Cover Plate CS, SS304, SS316, and PP Flange CS, SS304, SS316, PP Valve CS, SS304, SS316, PP Glass Toughened Borosilicate Connecton Flanged screwed or socket weld. Gauge valve Auto shut off ball check, off-set pattern Bolted or screwed bonnet. Drain/vent valve Ball type Fasteners ASTMA-193GrB7/A-194 Gr.2H. Option Anti frost extension for low temperature service heating /cooling arrangement. Glasses size a) 340x30x17mm b) 280x30x17mm c) 250x30x17mm Certification IBR

Note: In multi sections the gap between two sections is Upto10mm.
